Rededge MX
GIMBAL STABILIZZATA A MULTI SENSORE
Zoom ottico 30X RGB HD, Termocamera LWIR 640p con ottica 50mm
Rededge MX è un Gimbal ISR professionale Doppio Sensore IR-EO con
telecamera Zoom 30x FullHD e Sensore Termico 640x480p con ottica 25mm.
Il Design Industriale altamente integrato, la grande precisione e stabilizzazione in ogni condizione di utilizzo ed il potente processore integrato fanno di Gemini un Payload ISR multi sensore di riferimento per applicazioni di Videosorveglianza e Ricerca e Soccorso.
KEY FEATURES
Calibrated narrow bands
Five narrow high resolution (8 cm/pixel at 400 ft) spectral bands captured during one flight. Calibrated for precise, repeatable measurements.
Rugged and durable
New aluminum body for better durability and performance in higher temperatures. Global shutter imagers – no gimbal required and no moving parts.
Full flexibility
Compact size allows for integration with a wide variety of drones. Full access to raw data; outputs can be generated using a wide variety of processing and analysis platforms.
WATER MANAGEMENT
RedEdge-MX can provide powerful insights into water management. For example, color composites using the NIR band (like CIR) can help users identify overly damp areas. In addition, areas that are benefiting from excess irrigation will be highlighted.
PHENOTYPING
Manually measuring plant characteristics is time-consuming. RedEdge-MX captures more data in less time, allowing researchers to understand how different breeds react to certain environments and modify desirable traits in order to improve yield.
CROP HEALTH MAPPING
Low chlorophyll content is often an early indicator of plant stress. RedEdge-MX captures both visible and invisible spectral bands. From the different bands, it is possible to generate indices to see individual chlorophyll levels in the plants and compare over time.
FERTILIZER MANAGEMENT
RedEdge-MX not only allows for easy identification of areas low in nutrients but also help monitor the effects of fertilizer applications throughout the season and determine if, when, and where a new application is needed.
DISEASE IDENTIFICATION
RedEdge-MX captures a critical part of the light spectrum for studying plants (712–722 nm), called the red edge band. It is in this section of the spectrum that the first signs of stress start to show. Using analytics generated with the red edge band, growers can identify disease sooner and act faster to stop the spread.
SPECIES DIFFERENTATION
Some differences among species may not be visible to the naked eye. High-quality multispectral data allows for species differentiation by highlighting characteristics such as chlorophyll content, vigor, and leaf size.
ADVANCED CROP SCOUTING
High-quality multispectral imagery provides advanced field scouting capabilities. In one flight, it is possible to collect accurate and geotagged information of a problem, making easy to assess the situation and determine the appropriate intervention.
WEED DETECTION
Analytics developed with multispectral data can identify and highlight weeds, as weeds may have a different spectral signature than the planted crop.
TERRAIN MODELING
One of the advantages of a calibrated multispectral sensor is the generation of aligned outputs, which can be used to create digital surface models (DSM). A DSM provides insights into water management, land uses and terrain elevation.
LEAK SCOUTING
By measuring the reflectance on the red edge band, RedEdge allows the detection of irrigation leaks. The reflectance of the plants located in the areas with excessive irrigation varies from the rest of the field, oftentimes appearing healthier and showing high NDRE values.
NEED A DRONE?
Have a sensor, but need an integration kit? Looking for a full drone and sensor solution? Want hands on training?
LOOKING FOR A SOFTWARE SOLUTION?
With MicaSense you own your data. Visit our software solutions page and choose the platform that’s best for you, your customer.
Orthomosiac
Orthomosiac (3.26GB)
Fully processed orthomosaic captured in October 2021 in the Pacific Northwest over a pumpkin farm.
The pan-sharpened GSD of the flight is 2cm per pixel.
Note that the output format is GeoTiff and is intended to be viewed using GIS software (QGIS , ArcPro, ArcMap…).
RedEdge-MX Sensor Specifications
| Weight | 231.9 g (8.18 oz.) (includes DLS 2 and cables) |
| Dimensions | 8.7cm x 5.9cm x 4.54cm (3.4in x 2.3in x 1.8in) |
| External Power | 4.2 V DC – 15.8 V DC 4 W nominal, 8 W peak |
| Spectral Bands | Blue, green, red, red edge, near-IR (global shutter, narrowband) |
| Wavelength (nm) | Blue (475 nm center, 32 nm bandwidth), green (560 nm center, 27 nm bandwidth), red (668 nm center, 14 nm bandwidth), red edge (717 nm center, 12 nm bandwidth), near-IR (842 nm center, 57 nm bandwidth) |
| RGB Color Output | Global shutter, aligned with all bands |
| Ground Sample Distance (GSD) | 8 cm per pixel (per band) at 120 m (~400 ft) AGL |
| Capture Rate | 1 capture per second (all bands), 12-bit RAW |
| Interfaces | Serial, 10/100/1000 ethernet, removable Wi-Fi, external trigger, GPS, SDHC |
| Field of View | 47.2° HFOV |
| Triggering Options | Timer mode, overlap mode, external trigger mode (PWM, GPIO, serial, and Ethernet options), manual capture mode |
STANDARD KIT
REDEDGE-P KIT INCLUDES:
• RedEdge-Mx sensor
• DLS 2 with embedded GPS
• Lens cover
• SD card
• Calibrated Reflectance Panel (CRP)
• Cables and Mounting Screws
• Hard Carrying Case
• Quick Start Guide
DJI SKYPORT KIT
REDEDGE-P KIT INCLUDES:
• RedEdge-Mx sensor
• DLS 2 with embedded GPS
• Lens cover
• SkyPort Adapter
• SD card
• Calibrated Reflectance Panel (CRP)
• Cables and Mounting Screws
• Hard Carrying Case
• Quick Start Guide
